JBL

JBL Cinema SB160

Details
Item# JBLSB160BLKIN
Variations
Product Actions
Add to cart options
₹ 19,499.0019499.0 per system
₹ 19,999.00 Save 3%
Availability:

This item is currently not available.

Sold by: RPTech

For Bulk Enquiry: Click Here

220W power output

Incredible, powerful sound for an immersive cinematic experience.

Wireless subwoofer for extra deep bass

Enjoy deep and thrilling bass and clutter-free experience.

Dolby Digital embedded

Dolby Digital embedded for ultimate movie experience.

Wireless music streaming via Bluetooth

Stream and enjoy all your music wirelessly from any mobile device.

One cable connection with HDMI ARC

The one cable HDMI ARC connection allows for the simplest set-up and a hassle-free user experience.

General Specifications

Power supply 100 - 240VAC, ~ 50/60Hz
Total speaker power output (Max. @THD 1%) 220W
Soundbar power output (Max. @THD 1%) 2 x 52W
Subwoofer power output (Max. @THD 1%) 116W
Soundbar transducer 2 x (48 x 90)mm racetrack driver + 2 x 0.5" tweeter
Subwoofer transducer 5.25", wireless sub
Operating temperature 0°C - 45°C

Audio Specifications

Max SPL 82dB
Frequency response 40Hz - 20kHz
Audio inputs 1 Optical, Bluetooth (USB is for Service only.)

Dimensions

Soundbar dimensions (W x H x D) 900 x 67 x 63(mm) / 35.4" x 2.6" x 2.5"
Subwoofer dimensions (W x H x D) 170 x 345 x 313(mm) / 6.7" x 13.6" x 12.3"
Soundbar weight 1.65kg
Subwoofer weight 5kg
Packaging dimensions (W x H x D) 975 x 195 x 445mm / 38.4" x 6.7" x 17.5"
Packaging weight (Gross weight) 8.5kg

Control and Connection Specifications

Bluetooth version 4.2
Bluetooth profile A2DP V1.3/AVRCP V1.5
Bluetooth frequency range 2402MHz - 2480MHz
Bluetooth max. transmitting power <0dbm (EIRP)
Modulation type GFSK, π/4 DQPSK
2.4G Wireless frequency range 2400 - 2483MHz
2.4G Max. transmitting power 3dBm
USB port Type A
USB rating 5VDC/ 0.5A
Supporting file format mp3, wav
MP3 Codec MPEG 1 Layer 2/3
MPEG 2 Layer 3 Yes
MPEG 2.5 Layer 3 Yes
MP3 sampling rate 16kHz - 48kHz
MP3 bitrate 80kbps - 320kbps
80kbps - 160kbps (MPEG 2.5 Layer 3) Yes
WAV sample rate 16kHz - 48kHz
WAV bitrate Up to 3000kbps

Video Specifications

HDMI Video output (With Audio return channel) 1
HDMI HDCP version 1.4

Spec Sheet (English)

English 714 KB
  • Soundbar
  • Wireless subwoofer
  • Remote control with batteries
  • Power cords (up to 8pcs depending on region SKUs)
  • HDMI cable
  • Wall-mount bracket kit with screws
  • Quick start guide
  • Warranty card
  • Safety sheet
whats in box
The JBL Cinema SB160 features 220W system power, Dolby Digital, Optical and HDMI ARC, four powerful full range drivers and comes with a wireless subwoofer. Enjoy impressive, balanced sound with extra deep bass for movies and music entertainment. Plus, it’s Bluetooth-enabled so you can play your favorite music wirelessly from any smartphone, tablet or laptop and features a one cable HDMI ARC connection that ensures a hassle-free user experience.

Manuals & Downloads

The latest owner's manuals, quick start guides, and documents.

Declaration of Conformity

English 25 KB

Owners Manual (English)

English 3 MB

Spec Sheet (English)

English 714 KB
