110W power output
Incredible, powerful sound for an immersive cinematic experience.
Features
Wired subwoofer for extra deep bass
Enjoy deep and thrilling bass.
Dolby Digital embedded
Dolby Digital embedded for the ultimate movie experience.
Wireless music streaming via Bluetooth
Stream and enjoy all your music wirelessly from any mobile device.
One cable connection with HDMI ARC
The one cable HDMI ARC connection allows for the simplest set-up and a hassle-free user experience.
Specs & Downloads
Item# JBLSB130BLKIN-Z
Description
Extra Bass. Powerful sound.
The JBL Cinema SB130 features 110W system power, Dolby Digital, two full range drivers and comes with a wired subwoofer. Enjoy powerful sound with extra deep bass for movies and music entertainment. It’s Bluetooth-enabled so you can play your favorite music wirelessly from any smartphone, tablet or laptop and features a one cable connection with HDMI ARC that ensures a hassle-free user experience.
General Specifications
- Power supply
- 100 - 240VAC, ~ 50/60Hz
- Total speaker power output (Max. @THD 1%)
- 110W
- Soundbar power output (Max. @THD 1%)
- 2 x 27W
- Subwoofer power output (Max. @THD 1%)
- 56W
- Soundbar transducer
- 2 x 2" full range driver
- Subwoofer transducer
- 4", wired sub
- Operating temperature
- 0°C - 45°C
Audio Specifications
- Max SPL
- 82dB
- Frequency response
- 40Hz - 20kHz
- Audio inputs
- 1 Optical, Bluetooth (USB is for Service only.)
Dimensions
- Soundbar dimensions (W x H x D)
- 900 x 67 x 63mm
- Subwoofer dimensions (W x H x D)
- 150 x 320 x 220mm
- Soundbar weight
- 1.5kg
- Subwoofer weight
- 2.8kg
- Packaging dimensions (W x H x D)
- 975 x 170 x 355mm
- Packaging weight (Gross weight)
- 5.8kg
Control and Connection Specifications
- Bluetooth version
- 4.2
- Bluetooth profile
- A2DP V1.3/AVRCP V1.5
- Bluetooth frequency range
- 2402MHz-2480MHz
- Modulation type
- GFSK, π/4 DQPSK
- USB port
- Type A
- USB rating
- 5VDC/0.5A
- Supporting file format
- mp3, wav
- MP3 Codec
- MPEG 1 Layer 2/3
- MP3 sampling rate
- 16kHz - 48kHz
- MP3 bitrate
- 80kbps - 320kbps
- WAV sample rate
- 16kHz - 48kHz
- WAV bitrate
- Up to 3000kbps
MPEG 2 Layer 3
MPEG 2.5 Layer 3
80kbps - 160kbps (MPEG 2.5 Layer 3)
Country of Origin
- China
- -
Video Specifications
- HDMI Video output (With Audio return channel)
- 1
- HDMI HDCP version
- 1.4
What's in The Box?
- Soundbar
- Wired subwoofer
- Remote control with batteries
- Power cords (up to 4pcs depending on region SKUs)
- HDMI cable
- Wall-mount bracket kit with screws
- Quick start guide
- Warranty card
- Safety sheet
