Features
HyperCardioid Polar Pattern
JBL Commercial CSSM100 studio condenser microphone comes with a hypercardioid polar pattern that eliminates noise from the sides.
Condenser Capsule & Metal Body
With a rugged, metal body, the CSSM100 is reliable whether you're recording in the studio or on-stage. It's 14 mm condenser capsule ensures that you are heard, loud and clear.
Versatile and Rugged
The CSSM100 is a perfect choice for any artist seeking a high-quality mic to record anything – from vocals to acoustic instruments.
Specs & Downloads
Item# JBL-CSSM100
Description
Studio Condenser Microphone
JBL Commercial CSSM100 Studio Condenser Microphone is a general purpose Condenser Microphone that is ideal for Recording & On-Stage purposes. It can be used to record, both, vocals and instruments. With features like rugged metal body, hypercardioid pickup pattern, and a wide frequency response, you will #SoundYourBest with the CSSM100. The microphone uses a condenser capsule designed for 48-volt phantom powering & needs an external power supply.
General Specifications
- Transducer
- 14mm Condenser Capsule
- Polar Pattern
- HyperCardioid
- Frequency Response
- 20Hz – 20KHz
- Sensitivity
- -36dBV ±3dB (0dB=1V/Pa at 1KHz)
- Equivalent Noise Level
- ≤24dBA
- Peak SPL
- 110dB (THD≤ 1% at 1KHz)
- Electrical Impedance
- 100Ω
- Temperature Range
- -40 – 55° C
- Phantom Powering
- +48V ±4V
- Current Consumption
- 3 mA
Dimensions
- Net Weight
- 383g
Dia. 54mm
Length 148mm
