• Award Winner
JBL

JBL 306P MkII

Details
Item# 306PMKII-EU
Variations
Product Actions
Add to cart options
₹ 15,999.0015999.0 each ₹ 24,499.00 Save 35%
Availability:

In stock. Estimated delivery time 5-7 business days

Sold by: RPTech

For Bulk Enquiry: Click Here

General Specifications

LF Driver Size 165 mm (6.5")
HF Driver Size 25 mm (1")
HF Driver Type Soft dome
Crossover 1425Hz 4th order acoustic Linkwitz-Riley
Power Configuration Bi-amplified
HF Driver Power Amp 56 W Class D
LF Driver Power Amp 56 W Class D
Frequency Response 47Hz – 20kHz (±3dB)
Frequency Range 39Hz – 24kHz (-10dB)
Low Frequency Extension 39Hz (-10dB)
Maximum Continuous SPL 92dB
Maximum Peak SPL 110dB
Maximum Peak Input Level +6dBV / +20.3dBu (-10dBV / +4dBu)
System Distortion Criteria <10% THD at maximum output with full compressor / limiter engagement
Electrical Distortion Criteria 0.2% THD @ 1kHz / 2.83VRMS output; <1% THD @ 1kHz, full rated output
Signal to Noise Ratio 75dBA (A-Weighted), 70dBr (unweighted), relative to 2.83VRMS output
Coverage Pattern 120° x 90° (horizontal x vertical)
HF Trim Control -2dB, 0dB, +2dB
Boundary EQ LF Shelf @ 50Hz
AC Input Voltage 100 – 240VAC (±10%), 50 / 60Hz

Dimensions

Height 361 mm (14.2")
Width 224 mm (8.8")
Depth 282 mm (11.1")
Net Weight 6.1 kg (13.42 lbs)

Design

Enclosure Type Ported
Enclosure Construction 15mm MDF
Enclosure Finish Matte black PVC
Baffle Construction Injection-molded structural ABS

Audio Input

Analog Input Types 1 x XLR female, 1 x TRS female, balanced
Input Sensitivity 92dB / 1m (-10dBV Input)
  • 1 x 306P MkII studio monitor
  • 1 x Power cord
  • 1 x Quick setup guide
  • 4 x Peel-off rubber pads
whats in box
The next-generation JBL 306P MkII powered studio monitor makes legendary JBL performance available to every studio. With the revolutionary JBL Image Control Waveguide and refined transducers, JBL 306P MkII offers stunning detail, precise imaging, a wide sweet spot and impressive dynamic range that enhances the critical listening capabilities of any modern workspace. Featuring patented technologies derived from the JBL 7 Series and M2 Master Reference Monitors and sporting a sleek, modern design, JBL 306P MkII delivers outstanding performance and an enjoyable mix experience at an accessible price.
